Sale!
ASUS TUF GAMING B860M-PLUS WIFI DDR5 mATX Motherboard with LGA1851, 4x DIMMs 8800+ ,PCIe 5.0, WiFi 7, 2.5Gb LAN, USB 20Gbps, Type-C, Triple M.2, AI NPU Boost, For Intel Core Ultra Series 2 | USED

ASUS TUF GAMING B860M-PLUS WIFI DDR5 mATX Motherboard with LGA1851, 4x DIMMs 8800+ ,PCIe 5.0, WiFi 7, 2.5Gb LAN, USB 20Gbps, Type-C, Triple M.2, AI NPU Boost, For Intel Core Ultra Series 2 | USED

Original price was: 212 $.Current price is: 125 $.

Quantity
Categories: , ,

⚡ EXPERT FEATURES ~ USED

  • Next-Gen Intel Platform (LGA1851) : Built for Intel® Core™ Ultra Processors (Series 2), unlocking AI acceleration and next-gen compute power for gaming and productivity monsters.
  • 12+1+2+1 (80A) DrMOS Power Design : High-current VRM with premium stages delivers ultra-stable power for high-core CPUs under sustained load—no throttling, no drama.
  • DDR5 8800+ MT/s OC Dominance : Extreme-speed DDR5 support with AEMP III and DIMM Fit Pro extracts every MHz of performance from your RAM.
  • NPU Boost AI Overclocking : One-click BIOS feature boosts integrated NPU performance up to 24%—because AI workloads don’t wait.
  • PCIe 5.0 x16 SafeSlot : Future-proof GPU bandwidth with reinforced slot armor—handles next-gen GPUs without signal degradation.
  • Triple M.2 Storage Arsenal : Includes 1x PCIe 5.0 + 2x PCIe 4.0 slots for insane SSD speeds and massive storage scalability.
  • WiFi 7 + 2.5Gb Ethernet Combo : Ultra-low latency wireless + high-speed wired networking—pick your weapon, both are fast.
  • USB 20Gbps Type-C With DP Alt Mode : High-speed data + display output from a single port—clean, efficient, powerful.
  • Advanced Cooling Architecture : Enlarged VRM heatsinks, M.2 heatsinks, and multi-source fan control keep thermals under control under pressure.
  • DIY-Friendly Q-Design Ecosystem : PCIe Q-Release, M.2 Q-Latch, Q-Antenna, and Q-LED—build faster, upgrade easier, troubleshoot smarter.
  • Realtek 7.1 + DTS Audio Processing : High-fidelity audio with 98dB SNR, deep bass, and positional accuracy for competitive gaming.
  • Military-Grade TUF Durability : TUF chokes, capacitors, LANGuard, and ESD protection—this board is built like a tank.

📊 EXPERT SPECS

Component Details
Model ASUS TUF GAMING B860M-PLUS WIFI
CPU Support Intel® Core™ Ultra Processors (Series 2), LGA1851
Chipset Intel® B860
Memory 4x DDR5 DIMM, Up To 256GB
Memory Speed Up To 8800+ MT/s (OC)
Memory Features Dual Channel, XMP, AEMP III, DIMM Fit / DIMM Fit Pro
Expansion Slots 1x PCIe 5.0 x16, 1x PCIe 4.0 x4
Storage 3x M.2 (1x PCIe 5.0, 2x PCIe 4.0), 4x SATA 6Gb/s
RAID Support SATA RAID 0/1/5/10
Graphics Output 1x DisplayPort 1.4 (4K@60Hz), 1x HDMI 2.1 (4K@60Hz), USB-C DP Alt Mode
Ethernet Realtek 2.5Gb LAN + TUF LANGuard
Wireless Wi-Fi 7 (802.11be), 2×2, Up To 2.9Gbps
Bluetooth Bluetooth 5.4
Rear USB 1x USB-C 20Gbps, 2x USB-A 10Gbps, 4x USB-A 5Gbps, 1x USB 2.0
Front USB 1x USB-C 10Gbps, USB 5Gbps Header, USB 2.0 Header
Audio Realtek 7.1 HD Audio, Optical S/PDIF, DTS Processing
Cooling Headers CPU Fan, CPU OPT, AIO Pump, 3x Chassis Fans
Power Connectors 24-Pin ATX + 2x 8-Pin CPU
RGB 3x Addressable Gen 2 RGB Headers (Aura Sync)
Special Features NPU Boost, Q-Latch, Q-Release, Q-Antenna, Q-LED
BIOS 2x 128Mb UEFI AMI BIOS
OS Support Windows 11 (22H2 & Later)
Form Factor mATX (24.4 cm x 24.4 cm)
