CUDY AP3000 Outdoor AX3000 Wi-Fi 6 Access Point | IP65, 6kV Surge, 1.3GHz Dual-Core, PoE, 320m Range, 200 Devices, Mesh-Ready, MU-MIMO, Beamforming, High Power Antennas

CUDY AP3000 Outdoor AX3000 Wi-Fi 6 Access Point | IP65, 6kV Surge, 1.3GHz Dual-Core, PoE, 320m Range, 200 Devices, Mesh-Ready, MU-MIMO, Beamforming, High Power Antennas

58 $

Quantity
Categories: ,

Expert Features

  • Outdoor-Rated & Durable: Built with an IP65-rated weatherproof enclosure, ready for harsh environments like farms, parks, and parking lots.
  • Exceptional Wi-Fi 6 Performance: AX3000 dual-band speeds (2402 Mbps + 574 Mbps), with support for 160 MHz channels and 1024-QAM for up to 3 Gbps throughput.
  • Enterprise-Class Coverage: Equipped with 5 high-power PAs and a 3+2 antenna array, achieving up to 320 meters of range in open-air scenarios.
  • Surge & ESD Protection: 6 kV lightning/surge protection and 8 kV ESD resistance enhance reliability in thunderstorms.
  • Flexible Power Options: Supports both 802.3at PoE and 48~57V Passive PoE, with included power adapter.
  • High Device Capacity: Supports up to 512 devices, with 200 recommended for stable multi-client performance.
  • Adaptive Mesh Networking: Cudy Mesh enables seamless roaming and smart path switching via adaptive routing—ideal for large properties.
  • Plug-and-Play Setup: Add to your mesh with a single cable using the PoE port—no complicated setup required.
  • Smart Management Features: Includes Watchdog, Reboot Scheduling, and Cudy App for remote control and monitoring.
  • Secure & Smart: WPA3 encryption, WPS button, and guest network support ensure safe access.
  • Wall or Pole Mount: Versatile mounting kit included for professional installations in a variety of environments.



Expert Specs

Category Specification
Model Version AP3000 Outdoor 1.0
CPU 1.3 GHz Dual-Core CPU
Memory 256 MB DDR3 RAM
Storage 128 MB NAND Flash
Wi-Fi Standards Wi-Fi 6 (802.11ax), Dual-Band
Wi-Fi Speeds 5 GHz: 2402 Mbps / 2.4 GHz: 574 Mbps
Wi-Fi Streams 5 GHz: 3×3 MIMO / 2.4 GHz: 2×2 MIMO
Antenna Configuration 1× Internal + 2× External (RP-SMA Female)
Antenna Gain 5 GHz: 6 dBi / 2.4 GHz: 4 dBi
Power Amplifiers 5 Total: 3 (5 GHz) + 2 (2.4 GHz)
Range Performance Max: 320 m (1050 ft), Park: 280 m, Street: 70 m, Woods: 40 m
Beamforming Yes
PoE Input 802.3at PoE or 48–57V Passive PoE (via single GbE port)
Ethernet Ports 1× Shielded Gigabit RJ45 (PoE In)
Power Consumption Max: 18 W / Idle: 5 W
Buttons WPS, Reset
LED Indicators System LED
Operating Temp. Range -40°C to 70°C (-40°F to 158°F)
Protection IP65 Waterproof, 6 kV Surge, 8 kV ESD
Mounting Options Wall-Mounting, Pole-Mounting (Mount Kit Included)
Mesh Capabilities Cudy Mesh with Adaptive Routing, Seamless Roaming, Wired/Wireless Backhaul
Max Connected Devices 512 (Recommended Stable: 200)
Package Includes AP3000 Unit, Passive PoE Adapter, Mount Kit, Ethernet Cable, Quick Installation Guide
